Operating range

60 Hz operation. 0.1-150 m3/h* 0.4-660 US gpm up to 100 m (330 ft) LC* 0.1-300 m3/h* 0.4-1320 US gpm up to 155 m (500 ft) LC*. Temp. -30 °C to 150 °C* (-20 °F to 300 °F)*; up to 20 bar (290 psi). Capability of handling solids-laden fluids depending on shape, hardness and size of the solids. Consult factory. For higher temperatures and flow rates, see Richter series MNK (ISO/DIN) and MNKA (ASME/ANSI).

50 Hz operation. RMI 0.1-130 m3/h* 0.4-570 US gpm up to 70 m (230 ft) LC* RMA 0.1-250 m3/h* 0.4-1100 US gpm up to 110 m (360 ft) LC*

Features

• Maximum reliability through plain bearings with SAFEGLIDE® PLUS dry running optimisation (option)

• Minimised energy costs through optimised hydraulics

• Minimum service costs through minimised number of components and no setting work

• Maximum reliability, as the pump does not require O-rings

Specifications

• Design - Long life grease or oil bath lubrication

• Nominal Pressure - PN16

• Housing Material - EN-JS 1049 / ASTM A 395

• Flanges to ISO 7005-2, type B

• Certifications - 2006/42/EC Machinery Directive, 2014/34/EU Equipment explosive atmosphere
