Our Accuchiller TSE Series Central Chiller with Tank integrates a chiller with a complete process pumping system and reservoir in one package to minimize floor space. Units come fully assembled and wired, ready for quick and simple installation and include an insulated integral tank and pumping system mounted on the same frame. With a process pump and chiller pump as standard or with an optional dual standby or dedicated standby pumps, this package provides a wide range of options and configurations to suit any process need. All pumps are prewired to the control panel to save on costly field installation. All interconnecting piping, pumps, manifolds, and reservoir are insulated to prevent condensation and improve the system efficiency.

The advanced PLC uses a color touch-screen interface to make monitoring and control of the chiller and pumping system easy. TSE Series Central Chillers have a modular design that allows up to 12 refrigeration circuits to be combined into a single system for over 1,000 tons of cooling capacity. The chiller's innovative high flow design assures consistent process leaving water temperatures from 20°F to 80°F and as low as 5°F differential across the process.

TSE Series Chillers now come standard with Dynamic Lift technology to continuously calculate the lowest allowable refrigerant pressure for any combination of operating conditions for maximize chiller energy savings and more stable and smooth control of refrigerant pressure, especially under varying load and condenser inlet temperatures.

TSE Series Chiller with Tank Features

• Water-cooled and remote air-cooled condenser models available

• Advanced PLC Control System with high-resolution color touch-screen operator interface with an extensive list of operational information including compressor run hours

• Tank includes – pumps, tank, tank cover, water level sight glass, electric make-up valve, tank insulation, pump and trim insulation, insulated interconnecting piping to evaporator, pump starters and wiring of pumps to control panel

• Brazed plate evaporators maximize performance and increase resistance to costly freeze-up failures

• Compressor staging for capacity control with optional hot gas bypass for even greater unloading capabilities

• Scroll compressors last longer, increase efficiency and lower operating costs

• C-UL 508A listed and labeled control panel

• Compressor anti-cycle and start-up timer

• Lead/lag switch to alternate primary compressor

• In-line evaporator strainers assure full evaporator performance

• Water-cooled chillers include condenser water regulating valves

• Single point connection for electric hookup at control cabinet

• Cleanable frame mounted water-cooled condensers with removable heads (water-cooled only)

• Electronic expansion valves

• Liquid line solenoid valves to extend compressor life

• Refrigerant sight glasses

• Liquid line filter driers with removable cores

• High and low refrigerant pressure switches

• Alarm horn with silence button

• 3-phase power monitoring and safety protection

• 410a refrigerant

• Expert field start-up provided by qualified service personnel (optional)
