THERMAL CARE
EQ 1 TO 3 TON PORTABLE & PACKAGED CHILLERS
Accuchiller EQ Series Portable Industrial Chillers feature a compact footprint with an easily accessible interior and a PLC controller that provides precise temperature control and extensive diagnostics. Air-cooled, water-cooled and remote condenser models are packed with many standard innovative features that improve chiller performance and reliability.
Accuchiller EQ Series Features
Air-Cooled 1 to 3 tons
Water-Cooled 2 to 3 tons
Remote Condenser 3 tons
PLC controller provides diagnostics and precise temperature control
Nonferrous process fluid circuit
Generously sized air-cooled condensers for industrial environments with ambient temperatures up to 115°F
Internal insulated polyethylene reservoir with large capacity and a removable top
Condenser fan discharges air quietly through top of the chiller
Hot gas bypass provides accurate capacity control and extends compressor life
Process Y-strainer protects the evaporator from contaminants in the water
Stainless steel brazed plate evaporator with flow and temperature safeties to guard against freezing
Removable inlet air filter (air-cooled units only) is easily cleaned and protects condenser coils to assure maximum efficiency
High efficiency quiet fans
Modular hot gas bypass provides accurate capacity control and extends compressor life
Low voltage 24 VDC control keeps the control circuit signals free from AC interference
Water regulating valve keeps refrigerant pressure constant (water-cooled units only)
Evaporator freeze-up protection reduces potential for evaporator damage
Easily removable side panel allows for easy access to interior components
